Hoof trimming chute model 650-SP3

  • Easy maintenance
  • The KVK hoof support
  • Essential hydraulic functions as a standard
  • High focus on animal welfare and work flow
  • Double belly band system
SKU: 010650-SP3KVK Category:

Product benefits

Hoof support system

Rigid hoof support system that allows for the trimmer to use both hands for optimal workflow

Hydraulic functions

Essential hydraulic functions, which makes the workflow very efficient and effective

Easy maintenance

Galvanised and resistant towards an aggressive environment

Animal welfare

High focus on animal welfare and comfort with dampened hydraulic system

Product characteristics

The KVK model 650-SP3 is the ideal on-farm solution, which provides you with a chute developed with focus on optimal comfort for both cow and trimmer while at the same time providing an effective workflow. The chute enables the trimmer to meet todays’ demands for hoof trimming in a professional way. The chute is designed to perform hoof care on livestock between 200- 900 kg.

The KVK hoof support system
The Model 650-SP3 comes as a standard with 4 hydraulic hoof support plates as part of the hoof support system. This system provides a ridged surface for the trimmer to work against allowing for a more precise trim. The support plates are adjusted hydraulically from right to left, but manually in and out. This provide the possibility of adjusting the support plate individually, so they fit and support the hoof in the best way possible during the trim. This way of working enables a better overview of the hoof especially during treatments of hoof injuries and blocking the hoof.

Essential hydraulic functions
The 650-SP3 hoof trimming chute is equipped with all the essential hydraulic functions, which allows for a good work flow.

The hoof trimming chute has a hydraulic double belly band system, which gently supports the cow during the trim. This system also provides the possible of using the chute for other treatments (such as checking for udder cleft dermatitis), while it exposes the udder and minimizes the risk for the personnel doing examination and treatment.

The hydraulic front door opens both inwards and outwards in the full height of the chute providing a large and wide opening for the cow to exit the chute in. The gates of the front door can be adjusted in the width individually to accommodate larger and smaller livestock.

The model 650-SP3 has a large hydraulic back door, which is side-hinged and therefor can be used as part of the barrier when guiding the livestock into the chute. The design of backdoor also makes it optimal to use when guiding the cow the last part of the way into the chute while it gently guides the cow forward.

The hoof trimming chute model 650-SP3 is designed with a hydraulic lifting system, which can be individual adjusted, so it stops at the correct working height for you. This provides you with a  good working posture during the trim.

Easy maintenance
The KVK model 650-SP3 hoof trimming chute is a complete galvanised version, which makes it very resistant toward aggressive environments and durable.

The floor of the hoof trimming chute is covered with a thick rubber mat, which makes the floor easy to clean and less slippery for the livestock being trimmed. Furthermore the back of the floor is designed with a grid, so that faeces will not accumulate on the floor of the chute and thereby making sure that the hoof is not covered in faeces when entering the chute.

Effective work flow
One of the advantages of the hoof trimming chute model 650-SP3 having a side-hinged back door is that is allows for the back door to be used for extra storage. This storage opportunity provides an easy access to your equipment during the hoof trimming process.  The four LED working lights placed above the hooves provides the hoof trimmer with an excellent view off the hoof even in darker places. The standard gallow with a holder for the grinder gives a good work flow, while this enables you to bring the grinder with you from hoof to hoof.

Animal welfare
Animal welfare and comfort has always been an important value and in the forefront for design development at KVK. The starting point is the anatomy and movement of the cow.

The front gates are design to meet the cow in it’s movement, and not stop it abruptly by sideway moving doors. This is carried out with the front gates being able move from the inside of the chute towards the outside.

The front leg suspension is developed, so it enables the cow’s natural anatomical leg position not to be broken and thereby creating an overstretch or angling of the leg, which can result in an injury.

Much attention have ben paid to the individual components on the model 650-SP3 to make sure these are as noised reduced as possible, since this can help reduce the stress experienced by the cow and make the hoof trimming process more comfortable.

Technical information

The model 650-SP3 hoof trimming chute is CE approved, while it meets the strict requirements of the Machine Directive:

  • Directive 2006/42/EC
  • Annex I Essential Health And Safety Requirements
  • S/EN 60204-1
  • DS/EN ISO 13849-1
  • Directive 2004/108/EC



A standard model 650-SP3 includes the following
Hydraulic front winchOptional extra
Front gate open/closehydraulic
Back door open/closehydraulic
Double belly bandhydraulic
Lifting/lowering of the chutehydraulic
Leg winch all 4 legshydraulic
Adjustable hoof support plate (in/out, right/left)hydraulic
Individual working heightYes
Mechanical brakeOptional extra
Led working lights4 pcs.
Heating cabinetOptional extra
Hot-dip GalvanizedYes
Transport wheels4 (2x front and 2x back)
Gallow with a socketYes
Knives holders2 pcs.
Cup holder1 pcs
Hot air gun holder1 pcs
Rubber floor matYes
Hoof support systemYes
Socket3 pcs
General information
Length x width250 x 160 cm
Height with gallow215 cm
Lowest possible transport height215 cm
Height, lifted with gallow265 cm
Height on wheels230 cm
Standing length
Front gate to backdoor
Front gate to cross bar
195 cm
175 cm
Weight890 kg
Maximum lifting capacity at 150 barsChute: 3000 kg
Belly band (lift): 900 kg
Belly band (hold): 1600 kg
Surface treatmentHot dip galvanized
Livestock, optimal weight200-900 kg
Hydraulic and Electrical System
Electrical Motor3,0 kW
Hydraulic Pump unit max operating pressure180 Bar
Hydraulic system working pressure30-150 Bar
Hydraulic OilStandard 32
Electrical controlIndividual adapted to country specifications

Individual configuration
You can choose from a variety of extra such as Cup holder, LED working lights, mechanical breaks for the legs etc. On our webpage ww.kvk.dk you are able to build your own chute, so it meets your wishes and requirements.

Further information

Functionality & animal welfare
The from KVK hoof care and protects the to be treated animal. The hydraulic hoof fixation plates ensure that the hoofs are firmly fixed and the hoof trimmer can look at the hoof from above. This enables a natural feeling of work.

Maintenance and correct handling
KVK has summarized all the information you need to handle this hoof trimming chute properly in a manual which comes with the machine at delivery.

The right spare parts always at hand
If you need spare parts or have questions about the chute, do not hesitate to directly contact your personal KVK contact person. A list of spare parts can be found here and can be ordered individually and quickly, either independently or by arrangement.
